EXPERIMENTS

• E/O Converter Related Experiments :

• Input and output characteristics of an LED

• Input and output characteristics of an E/O Converter

• Intensity modulation principles

• Frequency characteristics of an E/O Converter

• O/E Converter Related Experiments :

• Input and output characteristics of an O/E Converter

• Overall frequency characteristics of an E/O and O/E combined

• Maximum transmission rate characteristics of an O/E Converter

• Optical PCM Communications :

• A/D Converter experiments

• PCM communications experiments using an Oscillator

• Voice transmission experiments

• Optical Data Communications :

• Input and output characteristics of RS-232C interface

• Parallel/Serial and Serial/Parallel conversion experiments

• Optical communications using personal computer

Features:

• E/O and O/E conversion and characteristics

• Optical PCM communication(trasmission&reception)

• Optical Data communications using personal computer

• DC power supply, a roll of fiber cable and the microphone included as peripherals
