Description



INSTRUCTION MANUAL



Do not plug in an appliance where the load exceeds 10Amp. Always ensure the plug of any appliance is fully inserted into the timer outlet. If cleaning of the timer is required, remove from mains power and wipe timer with a dry cloth.



INITIAL OPERATION







1. plug the timer into a regular 220-240 Volt household power point and turn the power on.



2. Leave for approximately 12 hours to charge the memory back up batteries.



SETTING CURRENT TIME



3. Press the CLOCK button and hold, simultaneously press the week button until the actual day is displayed. Continue by pressing HOUR or MINUTE button until the current hour or minute is displayed. When setting, the buttons week, hour or minute can be held down for rapid forward counting.



4. release both buttons. The week and time will be set.



5. to reset incorrect time, repeat previous steps.



SETTING PROGRAMS



6. press the timer button and release. The first on setting can be made now.



7. press week button to set the day or blocks of days. Set the time by pressing the hour button and then minute button.



8. press the timer button again to finish the first on setting and enter into the first off setting. By repeating 2 to make the first off setting.



9. press the timer button again to finish the first off setting and enter into the 2 on setting. Repeat 2 and 3 to program remaining settings.



10. after completing settings, Press the clock button and the timer is redy to operate.
