NETWORK Technology
GSM / CDMA / HSPA / EVDO / LTE
2G bands GSM 850 / 900 / 1800 / 1900 - SIM 1 & SIM 2 (dual-SIM model only)
CDMA 800 / 1900 - USA
, 4, 5, 7, 8, 3G bands HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100
CDMA2000 1xEV-DO - USA
BODY Dimensions 151 x 71.8 x 7.9 mm (5.94 x 2.83 x 0.31 in)
Weight 168 g (5.93 oz)
Build Glass front (Gorilla Glass 6), glass back (Gorilla Glass 6), aluminum frame
SIM Single SIM (Nano-SIM)
IP68 dust/water resistant (up to 1.5m for 30 mins)
Stylus, 42ms latency (Bluetooth integration, accelerometer, gyro)
DISPLAY Type Dynamic AMOLED, HDR10+
Size 6.3 inches, 98.6 cm2 (90.9% screen-to-body ratio)
Resolution 1080 x 2280 pixels, 19:9 ratio (401 ppi density)
Protection Corning Gorilla Glass 6
Always-on display
PLATFORM OS Android 9.0 (Pie), upgradable to Android 12, One UI 4
Chipset Exynos 9825 (7 nm) - EMEA/LATAM
Qualcomm SM8150 Snapdragon 855 (7 nm) - USA/China
CPU Octa-core (2x2.73 GHz Mongoose M4 & 2x2.4 GHz Cortex-A75 & 4x1.9 GHz Cortex-A55) - EMEA/LATAM
Octa-core (1x2.84 GHz Kryo 485 & 3x2.42 GHz Kryo 485 & 4x1.78 GHz Kryo 485) - USA/China
GPU Mali-G76 MP12 - EMEA/LATAM
Adreno 640 - USA/China
MEMORY Card slot No
Internal 256GB 8GB RAM
UFS 3.0
MAIN CAMERA Triple 12 MP, f/1.5-2.4, 27mm (wide), 1/2.55", 1.4µm, Dual Pixel PDAF, OIS
12 MP, f/2.1, 52mm (telephoto), 1/3.6", 1.0µm, PDAF, OIS, 2x optical zoom
16 MP, f/2.2, 12mm (ultrawide), 1/3.1", 1.0µm, Super Steady video
Features LED flash, auto-HDR, panorama
Video 4K@30/60fps, 1080p@30/60/240fps, 720p@960fps, HDR10+, stereo sound rec., gyro-EIS & OIS
SELFIE CAMERA Single 10 MP, f/2.2, 26mm (wide), 1/3", 1.22µm, Dual Pixel PDAF
Features Dual video call, Auto-HDR
Video 4K@30/60fps, 1080p@30fps
SOUND Loudspeaker Yes, with stereo speakers
3.5mm jack No
32-bit/384kHz audio
Tuned by AKG
COMMS WLAN Wi-Fi 802.11 a/b/g/n/ac/6, dual-band, Wi-Fi Direct, hotspot
Bluetooth 5.0, A2DP, LE, aptX
GPS Yes, with A-GPS, GLONASS, BDS, GALILEO
NFC Yes
Radio FM radio (USA & Canada only)
USB USB Type-C 3.1
FEATURES Sensors Fingerprint (under display, ultrasonic), accelerometer, gyro, proximity, compass, barometer
Samsung DeX, Samsung Wireless DeX (desktop experience support)
ANT+
Bixby natural language commands and dictation
Samsung Pay (Visa, MasterCard certified)
BATTERY Type Li-Ion 3500 mAh, non-removable
Charging Fast charging 25W
USB Power Delivery 3.0
Fast Qi/PMA wireless charging 12W
Reverse wireless charging 4.5W
MISC Colors Aura Glow, Aura White, Aura Black, Aura Pink, Aura Red
Models SM-N970F, SM-N970U, SM-N970U1, SM-N9700, SM-N970W, SM-N9700, SM-N970N, SM-N970X
SAR 0.85 W/kg (head) 1.08 W/kg (body)
SAR EU 0.21 W/kg (head) 1.52 W/kg (body)
TESTS Performance AnTuTu: 344442 (v7), 452400 (v8)
GeekBench: 10353 (v4.4), 2241 (v5.1)
GFXBench: 28fps (ES 3.1 onscreen)
Display Contrast ratio: Infinite (nominal)
Camera Photo / Video
Loudspeaker -26.2 LUFS (Good)
Audio quality Noise -92.8dB / Crosstalk -94.0dB
Battery life
Endurance rating 92h
